MORGUE CRISIS LIFT

PORTABLE DOCK LIFT FOR MOBILE MORGUES
Save on Transporting Time & Labor Costs







Morgue Crisis Dock Lift  MOBILE DOCK LIFT LOWERED HEIGHT

MORGUE DOCK LIFT     Morgue Mobile Dock Lift - Raised Height     MORGUE CRISIS LIFT - LOWERED HEIGHT





CAPACITY: 500 lb. uniform load.

PLATFORM: 30" x 74" smooth plate

BASE FRAME: 17-3/8" x 66-3/4" (approx) with maintenance device.

BASE FRAME FEATURE: Casters: Four swivel 5" texite casters mounted to end of base frame for lengthwise traverse. Two 8" cast iron with poly tread mounted in center. Includes one foot operated floor lock on one end.  Removable push bar included.

LOWERED HEIGHT: 14-1/2"

VERTICAL TRAVEL: 68"

RAISED HEIGHT: 82-1/2"

ELEVATING TIME: 41 seconds (approx.), Adjustable with pressure compensated flow control.

POWER UNIT: Internally mounted with 12 Volt DC motor, hydraulic pump, valving, and reservoir filled with oil.. Includes battery and charger mounted on shelf off end of lift.

PRIMARY VOLTAGE: 12VDC

CONTROL VOLTAGE: 12VDC

CONTROL: NEMA 4 handheld push button UP/DOWN. Includes 10 feet of straight cord (usable length may vary). ACTUATION One 2-1/2" double acting cylinder with chrome plated rod, power up/power down. BUSHINGS All pivot points equipped with Teflon lined bushings. Leg rollers have exclusive wear indicators.

FINISH: Red self-priming machinery enamel with platform painted beige.

PORTABLE CRISIS LIFT

Crisis Lift vs Wooden Ramp



CRISIS LIFT         vs.

WOODEN RAMP

REDUCED FOOTPRINT OF ONLY 16 SQUARE FEET (30" x 74")

LARGE & OBTRUSIVE FOOTPRINT OF 325+ SQUARE FEET (54’LONG BY 6’ WIDE) THAT WILL TAKE UP CRITICAL LOADING DOCK & PARKING LOT SPACE FOR THE LONG TERM

PROVIDES ALL WEATHER TRANSPORTING DUE TO FLEXIBILITY TRUCK RE-POSITIONING & CRISIS LIFT

STATIONARY TRUCK & WOODEN RAMP IS EXPOSED TO WEATHER ELEMENTS

HYDRAULICALLY RAISES TO MULTIPLE TRAILER HEIGHTS PROVIDING USAGE TO FUTURE MOBILE MORGUE INVENTORY ONLY AVAILABLE AT LOWERED HEIGHTS

CREATES RESTRICTIVE RAMP HEIGHT THAT WOULD BE LABORIOUS TO REVISE.

CREATES A LEVEL TRANSFER OF CORPSES TO TRUCK TO AVOID EMBARRASSING MOMENTS

PITCHED WOODEN RAMP, CAUSING BACK-ROLLING, SIDE ROLLING OR SPEED ROLLING BY TRANSPORTERS

ALLOWS SINGLE PERSON TO TRANSPORT THUS REDUCING DEPENDENCY ON HOSPITAL STAFF

REQUIRES ONE PERSON TO PULL + ONE PERSON TO PUSH A STRETCHER UP THE WOODEN RAMP

PROVIDES MORE PRIVACY & DIGNITY TO DECEASED BY CAREFUL AND PROFESSIONAL TRANSPORTING

LARGE FOOTPRINT ATTRACTS ATTENTION FROM ON-LOOKERS & SURVEILLANCE AND CAN CAUSE UNSAFE TRAVEL.

ALLEVIATES PERSONNEL BACK STRAIN TO REDUCE STAFF BURN-OUT/WORKERS COMP CLAIMS

STAFF IN TRAILER WILL HAVE TO CONTINUOUSLY BEND DOWN TO PICK UP 300+ LBS, THUS CAUSING STAFF BURN-OUT
